Aluminized


Aluminized Type 1:

Aluminized steel can be subjected to moderate forming, spinning and drawing operations without coating peeling or flaking. It is suited for applications where high temperatures are encountered and can be welded by conventional methods.


Because of its attractive appearance, painting often isn't required. This product offers superior corrosion and oxidation protection at high temperatures and maintains its strength at temperatures up to 650 degrees Celsius. Aluminized steels can also be a cost effective alternative to stainless steel since they frequently maintain their appearance better in service than do 409-type stainless steels.

Primarily used for automotive applications, Usibor® is a group of aluminum-silicon coated press hardenable steels ranging from 1500 to 2000 MPa nominal tensile strengths. Usibor® enables customers to fabricate parts with complicated geometry at very high strength levels without formability or springback challenges. Typical applications include anti-intrusion and safety cage components, including bumper beams, door beams, rockers, pillars, roof rails and cross members. Combining Usibor® with Ductibor® 1000 into laser welded blanks offers several significant advantages, including weight savings, improved crash behavior and cost savings through material and manufacturing optimization.

Features

We offer a wide range of precisely controlled chemical compositions with low residuals. Product attributes, additional offerings and capabilities include:

Surface treatments:

  • Oil
    Provides temporary corrosion protection and lubrication for forming operations.

  • Prelube

    Provides temporary corrosion protection and extra lubrication for forming operations.

Capabilities:

  • Gauge 0.020”-0.080” (0.508-2.032mm)

  • Width 36.00”-62.00” (914.40-1574.80mm)

  • Coating weights T1M 40 (T1-13), T1M 75 (T1-25), T1M-120 (T1-40), AS80 (40/40 g/m2), AS150 (70/70 g/m2)

  • Size capability may vary by specification. Please contact our sales department for specific information.

Grades

ASTM A463

Commercial steel type A, B, or C, Deep drawing steel (DDS), Extra deep drawing steel (EDDS)

ASTM A463

Structural steel grade 33, 37, 40

Structural Grades

SS gr33, 37, 40, 50 (Class 1, 2 or 3)

HSLA Grades

HSLA 40 ksi min yield, HSLA 50 ksi min yield, HSLA 55 ksi min yield, HSLA ksi 60min yield

Press Hardenable Steels: Usibor®

1500, 2000

Ductibor®

1000
